Trek Marlin 7 Gen 3 - Magic Mint
Trek Marlin 7 Gen 3 – Magic Mint
The Trek Marlin 7 Gen 3 in Magic Mint is built for riders who want a fast, confident hardtail that feels just as at home on the trail as it does on the daily commute. With its updated trail-ready geometry, the Marlin 7 delivers stability and control on rough terrain while still keeping things light and agile for the ride back home.
A RockShox Judy fork with 100mm of travel smooths out roots and rocks, giving you the confidence to take on more challenging trails. The SRAM NX Eagle 12-speed drivetrain offers a huge gear range for climbing steep hills or cruising the flats, all with smooth, reliable shifting. Hydraulic disc brakes provide consistent stopping power in any weather, so you can ride with total control no matter the conditions.
Finished in a stunning Magic Mint colourway, the Marlin 7 doesn’t just ride beautifully—it looks the part too. Whether you’re hitting your favourite singletrack or rolling through the city, this bike is ready to go wherever you do.
Key Features:
-
Lightweight and durable aluminium frame with trail-inspired geometry
-
RockShox Judy 100mm suspension fork for confident control
-
SRAM NX Eagle 12-speed drivetrain for smooth shifting and wide gearing range
-
Hydraulic disc brakes for reliable stopping power
-
Internal cable routing for a clean look and easier maintenance
-
Sleek Magic Mint finish that stands out on and off the trail
Specification
| Frameset | |
| Frame |
Size: XS
Alpha Silver Aluminium, curved top tube, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew
Size: S, M, ML, L, XL
Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew
|
| Fork |
Size: XS, S
RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travel
Size: ML, M, L, XL, XXL
RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travel
|
| Wheels | |
| Front Hub | Formula DC-20 LW, alloy, 6-bolt, 100x5 mm |
| Rear Hub | Formula DC-22LW, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm |
| Rear Skewer | 173x5mm Quick Release |
| Rim |
Size: XS, S, M, ML, L, XL Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve
Size: M, ML, L, XL
Bontrager Kovee, double-wall, Tubeless-Ready, 32-hole, 23 mm width, Presta valve
|
| Tyre |
Size: XS, S Maxxis Rekon, tubeless ready, EXO casing, folding bead, 60 tpi, 27.5x2.40''
Size: M, ML, L, XL
Maxxis Rekon, tubeless ready, EXO casing, folding bead, 60 tpi, 29x2.40''
|
| Rim Strip | Bontrager TLR |
| Drivetrain | |
| Shifter |
SRAM SX Eagle, 12-speed
|
| Rear Derailleur | SRAM NX Eagle, 12-speed |
| Crank |
Size: XS, S, M SRAM SX Eagle, 30T steel ring, 49 mm chainline, 170 mm length
Size: ML, L, XL
SRAM SX Eagle, 30T steel ring, 49 mm chainline, 175 mm length
|
| Cassette | SRAM PG-1210 Eagle, 11-50, 12-speed |
| Bottom Bracket | Truvativ Powerspline, 73 mm, threaded cartridge, 118 mm spindle |
| Chain | SRAM SX Eagle, 12-speed |
| Pedal | VP-536 Nylon Platform |
| Components | |
| Saddle |
Size: ML, M,XS ,L ,S ,XL
Bontrager Verse Short, Stainless Steel Rails
|
| Seatpost |
Size: XS, S TranzX JD-YSI34, 100 mm travel, internal routing, 31.6 mm, 350 mm length
Size: M
TranzX JD-YSI34, 125 mm travel, internal routing, 31.6 mm, 405 mm length
Size: ML ,L
TranzX JD-YSI34, 150 mm travel, internal routing, 31.6 mm, 456 mm length
Size: XL
TranzX JD-YSI34, 170 mm travel, internal routing, 31.6 mm, 500 mm length
|
| Handlebar |
Size: XS
Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width
Size: S
Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width
Size: ML , M , L , XL
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
|
| Grips |
Trek Line Comp, Nylon Lock-On
|
| Stem |
Size: XS, S
Bontrager Comp, 31.8 mm, 7-degree, 35 mm length
Size: M, M/L, L
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Size: XL
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 60 mm length
|
| Headset |
Size: ML, M ,XS ,L ,S ,XL
Semi-integrated, 1-1/8''
|
| Brake | Shimano MT200 Hydraulic Disc |
| Brake Rotor |
Size: XS , S , M , ML , L , XL Shimano RT26, 6-bolt, 160 mm
Size: M , ML , L , XL
Shimano RT26, 6-bolt, 180 mm
|
| Weight | |
| Weight | M - 14.15 kg / 31.2 lbs |
| Weight Limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
Sizing
How tall are you?
To measure your height, stand up straight, barefoot, with your back, heels, shoulders and head all touching a wall. While looking straight ahead, place a book or straight edge on your head and slowly push it against the wall. Your straight edge should be parallel with the floor. Mark the spot where the bottom of the book is touching the wall. The distance from the marked spot to the floor is your height.
What is your inside leg?
How to measure: Stand barefoot with your back straight and against a wall. Tuck a ruler or something that extends to the floor between your legs. Using both hands, and keeping it level, pull the ruler up into your crotch as if you were sitting on the saddle. Measure the distance from the top edge of the ruler to the ground to find your inside leg measurement. Your inside leg is very important to your final bike size so please measure carefully.
| Size | Rider Height | Inseam |
| XS | 145 - 155 cm | 69 - 73 cm |
| S | 155 - 165 cm | 74 - 78 cm |
| M | 165 - 177 cm | 79 - 83 cm |
| M/L | 173 - 180 cm | 81 - 86 cm |
| L | 177 - 188 cm | 84 - 89 cm |
| XL | 188 - 195 cm | 89 - 91 cm |
