Orbea Wild M-Team - Electric Dual Suspension - One of a Kind

Orbea Wild M-Team Dual Suspension Electric Bike - One of a Kind

We have specially reserved one of the award winning Orbea Wild FS eMTB's. This bike has been customised by us! We have customised the paint job, and upgraded the Dropper Seat Post, Handlebars, and Tyres! Also features the new Bosch Perfance CX Gen 5 motor with upto 100Nm of torque. Be quick as there is only one of these bikes!

Introducing the Orbea Wild M-Team electric bike, engineered for mountain biking enthusiasts who demand peak performance. This premium electric bike features a powerful motor and lightweight frame, allowing you to tackle the toughest terrains with ease. Equipped with advanced suspension and high-quality components, the Wild M-Team ensures exceptional comfort and agility on every ride.

Roam further and ride longer with its durable battery, designed to keep up with your adventurous spirit. The sleek, modern design not only enhances performance but also turns heads on the trails. Elevate your mountain biking experience with the Orbea Wild M-Team electric bike and conquer every challenge in your path!

Features

• 170mm of Gravity-Tuned Suspension
  Wild offers 170mm of travel front and back, with custom-tuned Fox Float X or Float X2 shocks and the 38 fork.

• Mullet Ready
  Whether you want maximum speed with 29" or to focus on fun with 27", Wild has you covered.

• Modular Battery System
  Wild comes with the 750Wh as standard. This lighter battery offers the ultimate in handling. For those looking for a litter ride the 625Wh battery, may be available upon request.

• Bosch CX Performance Motor
  BOSCH's 85 Nm motor needs no introduction, with endless power and controlled responses. The updated motor gives more precise control, is quieter and lighter, and offers less pedal resistance.

• OMR Carbon
  High modulus, high-strength fibres, and advanced carbon manufacturing techniques let us use less carbon while maintaining strength and rigidity.

• Fox 38 Fork
  Full power eBikes need stiffer, more burly forks. Wild counts on the benchmark Fox 38.


Specification

Frameset
Frame	Orbea Wild OMR 2025, 29" wheels, Concentric Boost 12x148
Shock	Fox Float X2 Factory Trunnion 2-Pos Adjust Kashima custom tune 205x65mm
Fork	Fox 38 Float Factory 170 Grip X2 QR15x110 Kashima
Steerer Tube	Alloy 1-1/2", Black Oxidated Bearing
Electric Bike
Battery	Bosch Powertube 750Wh Horizontal BBP3770
Range Extender	N/A
Motor	Bosch Performance Line CX Gen 5 (up to 100Nm)
Display	Bosch System Controller BRC3100
Charger	Bosch Charger 4A (230V) BPC3400
Remote	Bosch Mini Remote BRC3300
Drivetrain
Chainring	e*thirteen e*spec Direct Mount 34T Boost
Crank	e*thirteen Plus Alloy
Shifters	Shimano XT M8100 I-Spec EV
Cassette	Shimano CS-M8100 10-51t 12-Speed
Rear Derailleur	Shimano XT M8100 SGS Shadow Plus
Chain	Shimano M8100
Chainguide	e*thirteen Plus Bosch CX Gen4 CL 55 32-36t
Cockpit
Handlebar	OC Mountain Control MC10 Carbon, Rise 35, Width  800
Stem	OC Mountain Control MC11 Alu SL, 0º
Computer Mount	OC Computer Mount CM-05, Garmin/Sigma
Brakes
Brakes	Shimano XT M8120 Hydraulic Disc
Rotors	Galfer Wave Rotors 203mm front / 203mm rear
Brakes Configuration	N/A
Wheels
Wheels	Oquo Mountain Control MC32TEAM POWER
Tyres	Maxxis Assegai 2.50" DH TR(F) / Minion DHR II 2.40" DH  TR(R)
Components
Seatpost	Fox Transfer Factory Kashima Dropper  31.6x411/150mm
Seatpost Lever	Shimano SL-MT500 I-Spec EV
Saddle	Fizik Aidon 208x145mm manganese rail
Grips	Ergon GE10
Accessories
Lights	N/A



Sizing

S	150 cm - 175 cm
M	160 cm - 185 cm
L	170 cm - 195 cm
XL	180 cm - 205 cm

Geometry

	S	M	L	XL
1. Seat Tube (C-T)	415	415	435	450
2. Top Tube (EFF)	563	586	612	639
3. Head Tube	110	120	130	140
4. Chainstay	448	448	448	448
5. BB Drop	22	22	22	22
6. BB Height	358	358	358	358
7. Wheelbase	1228	1252	1285	1311
8. Head Angle	63.5	63.5	63.5	63.5
9. Seat Angle	77.5	77.5	77.5	77.5
10. Rake	44	44	44	44
11. Standover	730	730	730	730
12. Reach	435	455	480	505
13. Stack	625	634	643	652
14. Fork Length	585	585	585	585
